R3131 Spectrum Analyzer Operation Manual

2.3 Measurement Examples

2-77Apr 10/98

Performing the window sweep

13. Press Window Sweep ON/OFF.

A window sweep is performed. The sweep is completed more quickly because

only the area within the measuring window is swept.
