R3131 Spectrum Analyzer Operation Manual
2.4 Other Functions
2-88 Aug 28/98
2.4.2 Saving or Recalling Data
(1) Saving Data
Data which can be saved to internal memory or to a floppy disk include the following:
• measurement conditions
• 501-point trace A (or B), or trace data for both A and B
NOTE: Trace data can be saved in Write or View mode only.
• The level values for trace data (Floppy disk only)
• Antenna correction data (Floppy disk only)
• Normalize deta (Available only when equipped with Option 74)
To save data, use the following procedure:
1. Press SHIFT and RECALL(SAVE).
The Save menu and the file list are displayed.
2. Press
Device RAM/FD
.
This selects either RAM (internal memory) or FD (floppy disk) as the file desti-
nation.
NOTE: FD cannot be selected if a floppy disk is not present in the floppy disk drive.
Figure 2-84 Screen Display Showing Floppy Disk as the Destination
