R3131 Spectrum Analyzer Operation Manual

3.3 Menu Function Descriptions

3-41

3.3.17 PK SRCH Key (Peak Search)

Pressing this key displays the frequency and level of the marker after moving the marker to the maximum

level of the trace within the search range. (Note there is no menu associated with this panel key.)
