4.1 GPIB Remote Programming
4-26 Aug 28/98
Table 4-23 Calibration
Table 4-24 Data Save/Recall (1 of 2)
*: “FD:” means the floppy disk drive.
Function Listener Code
Talker Request
Code Output Format
CAL ALL CLA ––– –––
Total gain CLG ––– –––
IF step AMP CLSTEP ––– –––
IT1 ––– –––
RBW switch CLRBW ––– –––
IT2 ––– –––
Log linearity CLLOG ––– –––
IT3 ––– –––
AMPTD MAG CLMAG ––– –––
IT4 ––– –––
PBW CLPWB ––– –––
IT6 ––– –––
CAL level CLN* CL? Level
ON CLN* CLON? 0: OFF
1: ON
OFF
CLF
f correction ON FC ON FC? 0:OFF/ 1:ON
FCN
OFF FC OFF
FCF
CAL correction ON CC ON CC? 0:OFF/ 1:ON
CCN
OFF CC OFF
CCF
Function Listener Code
Talker Request
Code Output Format
Save register SV1 ––– –––
SV2 ––– –––
SV3 ––– –––
SV4 ––– –––
SV5 ––– –––
SV6 ––– –––
SV7 ––– –––
SV8 ––– –––
SV9 ––– –––
SV10 ––– –––
Save file SV FD: file name
(*)
––– –––
