R3131 Spectrum Analyzer Operation Manual

4.1 GPIB Remote Programming

4-30 Aug 28/98

Table 4-30 Data Input

Function Parameter

Numeric value 0

Decimal point .

Minus sign -

Plus sign +

Exponent EXP

GHz GZ

MHz MZ

KHz KZ

Hz HZ

mW MW

dB DB

mA MA

Second SC

Millisecond MS

MSEC

Microsecond US

USEC

Nanosecond NSEC

Enter ENT

Volt VOLT

Millivolt MV

Microvolt UV

Nanovolt NV

%PER
