ADVANTEST R3131

R3131 Spectrum Analyzer Operation Manual
4.1 GPIB Remote Programming
4-29Aug 28/98
Table 4-29 Miscellaneous
(*1): When an error occurs, the corresponding bit OR value is the return value.
(*2): See error number(s) listed in APPENDIX 1 ERROR MESSAGE.
Function Listener Code
Talker Request
Code Output Format
Delimiter
CR LF<EOI> DL0 ––– –––
LF DL1 ––– –––
<EOI> DL2 ––– –––
CR LF DL3 ––– –––
LF<EOI> DL4 ––– –––
↑ step up UP ––– –––
↓ step down DN ––– –––
knob-up coarse CU ––– –––
fine FU ––– –––
knob-down coarse CD ––– –––
fine FD ––– –––
Indication ON ANNOT ON ANNOT? 0: OFF
1: ON
OFF ANNOT OFF
Date SETDATE SETDATE? YYMMDD
(for example: 980528)
Time SETTIME SETTIME? HHMMSS
(for example: 130530)
Device ID output ––– *IDN? Manufacturer name, Model,
0, Revision
(for example: ADVANTEST,
R3131, 0, A00)
Self Test ––– *TST? 1 : CPU (*1)
2 : A/D
4 : Lock Detector
8 : Total Gain
16: Cal Signal
32: RF ATT
64: Variable Gain AMP
128: IF Step AMP
256: RBW SWB
Error number output ––– ERRNO? Integer (*2)
