R3131 Spectrum Analyzer Operation Manual
1.3 Operating Environment
1-6 Apr 10/98
Figure 1-2 Replacing the Power Fuse
Fuse holder
Pull out the fuse holder using a slotted
head screwdriver.
Fuse (T5A compliant)
Check (and replace if
necessary) the power fuse and
put it back into the fuse holder.
Spare fuse attached to the fuse holder.
Fuse holder
