R3131 Spectrum Analyzer Operation Manual
2.2 Basic Operation
2-19Apr 10/98
Setting the measurement conditions
This changes the analyzer settings so that the input signal is displayed more clearly.
9. Press FREQ.
The current center frequency is displayed in the active area, and the Freq menu
used to select the frequency type appears on the right.
Figure 2-6 Active Area Display
10. Press 3, 0 and MHz.
A center frequency of 30 MHz is set.
Figure 2-7 Setting the Center Frequency
