R3131 Spectrum Analyzer Operation Manual
1.4 System Checkout
1-9Jul 10/98
Figure 1-5 Screen Display after Self Tests have Completed
5. Press SHIFT.
The SHIFT lamp lights.
6.Press CONFIG(PRESET).
The factory defaults are reset.
The startup screen is displayed as shown in Figure 1-5.
7. Press SHIFT and 0.
The Self Test menu is displayed.
NOTE: Pressing SHIFT and 0 turns the Self Test mode on. In this mode, only the SHIFT, PRESET and
COPY keys, and the currently displayed soft menu can be used. All other panel keys are disabled.
Figure 1-6 Self Test Screen
