3.4 Setting Values
3-57Aug 28/98
3.4 Setting Values
This section shows the values of various settings used with the spectrum analyzer.
3.4.1 Set Resolution
This section lists the center frequency set resolution and the frequency span set resolution for each
frequency span.
Table 3-1 Center Frequency Set Resolution vs. Frequency Span
Table 3-2 Frequency Span Set Resolution vs. Frequency Span
Frequency span Center frequency set resolution
100MHz ≤ Span 100kHz
10MHz ≤ Span < 100MHz 10kHz
1MHz ≤ Span < 10MHz 1kHz
100kHz ≤ Span < 1MHz 100Hz
50kHz ≤ Span < 100kHz 10Hz
0Hz = Span 10Hz
Frequency span Frequency span set resolution
400MHz < Span 1MHz
40.0MHz < Span ≤ 400.0MHz 100kHz
1.00MHz < Span ≤ 40.00MHz 10kHz
100kHz < Span ≤ 1.000MHz 1kHz
50.0kHz ≤ Span ≤ 100.0kHz 100Hz
