R3131 Spectrum Analyzer Operation Manual
4.1 GPIB Remote Programming
4-19Jul 10/98
Table 4-10 Marker →
Table 4-11 Trigger
Function Listener Code
Talker Request
Code Output Format
MKR→CF MKCF ––– –––
MC ––– –––
MKR∆→CF MTCF ––– –––
MKR→REF MKRL ––– –––
MR ––– –––
Peak→CF PKCF ––– –––
Peak→REF PKRL ––– –––
MKR∆→SPAN MTSP ––– –––
DS ––– –––
MKR→CF step MKCS ––– –––
M0 ––– –––
MKR∆→CF step MTCS ––– –––
M1 ––– –––
MKR→MKR step MKMKS ––– –––
M2 ––– –––
MKR∆→MKR step MTMKS ––– –––
M3 ––– –––
Marker→Trace A MKTRACE TRA MKTRACE? 0: Blank
1: A Trace
2: B Trace
Marker→Trace B MKTRACE TRB
Function Listener Code
Talker Request
Code Output Format
Trigger mode ––– TM? 0: Free run
1: Line
2: Video
5: Ext
FREE RUN TM FREE ––– –––
FR ––– –––
LINE Trigger TM LINE ––– –––
LI ––– –––
VIDEO Trigger TM VID ––– –––
VI* VI? Level (integer)
External Trigger TM EXT ––– –––
EX* EX? Level (real value)
Trigger slope + TRIGSLP+ TRIGSLP? 0: +
1: -
- TRIGSLP-
