ADVANTEST R3131 User Manual

R3131 Spectrum Analyzer Operation Manual
4.1 GPIB Remote Programming
4-24 Aug 28/98
Table 4-20 ACP
Table 4-21 TG (Option 74)
Function Listener Code
Talker Request
Code Output Format
ACP execution ACP ACP? Lower, Upper
ON ACP ACPON? 0: OFF
1: ON
OFF ACP OFF
ACP CS ADCH* ADCH? Channel Spacing (adjacent)
ACP BS ADBS* ADBS? Specified Bandwidth
ACP (alternate) ADCHSC[ON]* ADCHSC? Channel Spacing (alternate)
––– ACPSC?
Lower 1, Upper 1, Lower 2, Upper 2
ON ADCHSC[ON] ADCHSCON? 0: OFF
1: ON
OFF ADCHSC OFF
ACP graph ON ADG [ON] ADG? 0: OFF
1: ON
OFF ADG OFF
Function Listener Code
Talker Request
Code Output Format
TG ON TG TG? 0: OFF
1: ON
OFF TGF
TG level TGL* TGL? TG level
TG freq. adjust TGM* TGM? Frequency
TG freq. adjust auto TGA ––– –––
Execute Normalize NORM EX ––– –––
Normalize ON NORM ON NORM? 0: OFF
1: ON
OFF NORM OFF
