R3131 Spectrum Analyzer Operation Manual
5 SPECIFICATIONS
5-5*Aug 28/98
(8) General Specifications
(9) Specifications for the instrument equipped with TG option (Option 74)
Characteristics Description
Operating environment range 0°C to +50°C, Relative humidity 85% or less (without condensation)
Storage environment range -20°C to +60°C, Relative humidity 85% or less
AC input power source Automatic switching to 100VAC or 200VAC
For 100VAC : 100 to 120VAC, 50 to 60Hz
For 200VAC : 220 to 240VAC, 50 to 60Hz
Power consumption 200VA or below
Mass 12 kg or less
Dimensions approximately 424 (W) x 177 (H) x 300 (D) mm
(not including projections such as rubber feet and connectors)
Characteristics Description
Frequency range 100kHz to 3.0GHz
Output level range
(Resolution)
0 to -59.9dBm
(0.1dB step)
Output level accuracy > ± 0.5dB
(30MHz, -10dBm, 20°C to 30°C)
Output level flatness > ± 1.0dB (100kHz to 1GHz)
> ± 1.5dB (100kHz to 3GHz)
(-10dBm, referenced to 30MHz)
Output level switching error > ± 1.0dB (100kHz to 1GHz) (output level P -30dBm)
> ± 2.0dB (100kHz to 2.6GHz)
> ± 3.0dB (9kHz to 3.0GHz)
(referenced to -10dBm)
Output spurious
Harmonics
Non-harmonics
> -20dBc (output level = -10dBm)
> -30dBc (output level = -10dBm)
Dynamic range
(TG leakage)
> -100dBm
(input ATT 0dB)
Output VSWR > 2 (nominal)
(output level > -10dBm)
Maximum input signal level ± 15dBm
± 10V
Mass 1 kg or less
