Output VSWR:
Electronic attenuator
For output levels < 0 dBm
Frequency Output VSWR
≤ 2 GHz
1.25:1
≤ 3 GHz
1.40:1
≤ 4 GHz
1.50:1
≤ 6 GHz
1.60:1
For output levels > 0 dBm, VSWR is < 1.5:1, ≤ 4 GHz, < 1.8:1, ≤ 6 GHz
Mechanical attenuator
For output levels < 0 dBm
Frequency Output VSWR
≤ 3 GHz
1.33:1
For output levels > 0 dBm, VSWR is < 1.5:1, ≤ 3 GHz
No attenuator
Frequency Output VSWR
≤ 4 GHz
< 1.5:1
≤ 6 GHz
< 1.8:1
Attenuator repeatability
Mechanical attenuator
typically 0.1 dB
RF output connector:
Front panel 50 Ω, type N female connector to MIL-PRF-39012 Class 2
Output protection:
Protects the instrument from externally applied RF power (from a 50 Ω source) of 50 W
up to 3 GHz or 25 W up to 4 GHz.
The RPP trip can be reset from the front panel or via the remote interface. For safety,
protection is also provided when the instrument is switched off.
3416 damage level 0.5 W (+27 dBm) from a max 5:1 VSWR, all frequencies.
RF optimization modes:
Mode Attenuator option Maximum RF output power (PEP)
< 10 MHz 10 to
1000 MHz
1000 to
2000 MHz
2000 to
3000 MHz
3000 to
3750 MHz
3750 to
4000 MHz
4000 to
6000 MHz
Power
No attenuator +21 dBm +22 dBm +22 dBm +22 dBm +20 dBm +17 dBm +18 dBm
Relay attenuator +16 dBm +19 dBm +19 dBm +16 dBm — — —
Electronic attenuator +13 dBm +16 dBm +16 dBm +16 dBm +13 dBm +10 dBm +8 dBm
Noise
No attenuator +15 dBm +16 dBm +16 dBm +16 dBm +14 dBm +11 dBm +12 dBm
Relay attenuator +10 dBm +13 dBm +13 dBm +10 dBm — — —
Electronic attenuator +7 dBm +10 dBm +10 dBm +10 dBm +7 dBm +4 dBm 2
ACP
No attenuator +6 dBm +6 dBm +6 dBm +6 dBm +6 dBm +6 dBm +6 dBm
Relay attenuator +4 dBm +4 dBm +4 dBm +4 dBm — — —
Electronic attenuator 0 dBm 0 dBm 0 dBm 0 dBm 0 dBm
−2 dBm −4 dBm
