REMOTE OPERATION POWER COMMANDS
4-150
[SOURce]:POWer[:LEVel][:IMMediate][:AMPLitude]:OFFSet
:ATTenuation
Description: Sets the external attenuation value for power offset.
Note that gain, attenuation and system loss are added together to give the overall offset.
Actual RF output power = displayed RF level − gain value + attenuation value + system
loss value.
Parameters: <numeric_value>
Valid values: <NRf>(dB) | MINimum | MAXimum
*RST sets: 0 dB
[SOURce]:POWer[:LEVel][:IMMediate][:AMPLitude]:OFFSet
:ATTenuation?
Description: Returns the external attenuation value for power offset.
Parameters: None
Response: <NR2>
Returned values: Attenuation level (dB)
[SOURce]:POWer[:LEVel][:IMMediate][:AMPLitude]:OFFSet[:GAIN]
Description: Sets the external gain value for power offset.
Note that gain, attenuation and system loss are added together to give the overall offset.
Actual RF output power = displayed RF level − gain value + attenuation value +
system loss value.
Parameters: <numeric_value>
Valid values: <NRf>(dB) | MINimum | MAXimum
*RST sets: 0 dB
[SOURce]:POWer[:LEVel][:IMMediate][:AMPLitude]:OFFSet[:GAIN]?
Description: Returns the external gain value for power offset.
Parameters: None
Response: <NR2>
Returned values: Gain level (dB)
