LOCAL OPERATION CONTROLS AND CONNECTORS
3-8
Increment/decrement keys and rotary control
Control knob When enabled by the [KNOB/STEP] key, adjusts the value of the selected
parameter.
10
When KNOB is enabled, increases the knob resolution by a factor of 10.
When STEP is enabled, increments the current function by one step.
KNOB
STEP
Switches between enabling the control knob and step operation.
x10
When KNOB is enabled, decreases the knob resolution by a factor of 10.
When STEP is enabled, decrements the current function by one step.
Output control and diagnostic keys
RF
ON/OFF
Toggles the RF output on and off.
MOD
ON/OFF
Toggles all
modulation on and off, overriding any individual modulation
paths currently selected. MOD ON or MOD OFF is displayed on the main
screen.
SOURCE
ON/OFF
Toggles the current modulation path on and off.
ERROR
STATUS
Displays the error status menu, which provides additional diagnostic
information.
