154 Agilent 1200 Series Autosampler Reference Manual
4 Repairing the Autosampler
7 Install the belt. 8 Install the metering-head assembly (see “Gripper Arm” on
page 128).
On completion of this procedure:
• Install the top cover (page 134).
• Verify the transport assembly alignment (page 102).
