Agilent 1200 Series Autosampler Reference Manual 171
Repairing the Autosampler 4
9 Install the bottom foam. Ensure the cables are positioned
as shown.
On completion of this procedure:
• Install the ASM board (page 157).
• Install the fan (page155). Install the sampling unit
(page 141).
