Agilent Technologies 3070 Series User Manual

© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 7-8
Chapter 7: Site Preparation – Compressed Air and Vacuum Requirements: Vacuum Requirements
Figure 7-4 3X7X Series 3 and 79000 vacuum port locations
307X Series 3 Testhead with Support Bay
E1135C PDU (Main)
E1135C PDU (Main)
E1135C PDU (Branch)
View with rear
door open
317X Series 3 Testhead
Port2
Port3
In
0ut
Port3
Port2
In0ut
E1135B or E1135C PDU (Main)
79000 Testhead
Port1
Port0 Port2
Port3
In
E1135C PDU (Main)
3279 Series 3 Testhead
0ut
Port3 Port2
Optional Optional
E9998-63200
2-Module Manifold*
E9900-63200
4-Module Manifold
*Note: The E9998-63200 manifold will not work on the 3279 or 79000 testhead
In0ut
