Agilent Technologies 3070 Series - 307 X 4-Module 1-PDU System AC Outlets

© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-50
Chapter 10: Site Preparation – Power Requirements for Older Systems: Series 3 Power Requirements and Connections (Prior to May 2001)
307X 4-Module 1-PDU System AC Outlets
Figure 10-35 307X 4-module 1-PDU system
Outlet 0
Support Bay
(Rear View)
Testhead (Rear View)
Outlet 2
Outlet 3Outlet 1
