© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-112
Chapter 10: Site Preparation – Power Requirements for Older Systems: Tester Power Requirements (Series I/II)
Connecting a Pigtail to the E1135C PDU
The E1135C PDU is the replacement for the E1131A,
and E1135A/B PDUs. The input terminals on the
E1135C on the mains disconnect switch easily fit
conductor size 10 square millimeters (#8 AWG). It is
strongly suggested that if the recommended conductor
size
1
in the following tables is greater than 10 square
millimeters (#8 AWG), that a 450 mm (18-inches) to
609 mm (24-inches) pig tail be created using 10 square
millimeters (#8 AWG) conductor, and the recommended
larger cable be connected to the pigtail. See
Connecting a Pigtail to the E1135C PDU on
page 11-84.
1 It is difficult to fit conductor size 16 square millimeters (AWG 6) into the mains disconnect switch, and 25 square millimeters (AWG 4)
will not fit. With an 450 mm (18-inches) to 690 mm (24-inches length pigtail, 10 square millimeters (#8 AWG) will safely carry the 3070
load)
