© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 9-3
Chapter 9: Site Preparation – Receiving and Moving Instructions: Uncrating The System
Uncrating The
System
This section contains:
■ Uncrating an Agilent 3070 Series I System, 9-3
The customer should removed the tri-wall box from the
pallet. The Agilent CE will uncrate the system pallets.
The systems are shipped on pallets as described in
Tab le
9-1.
Leave the smaller boxes intact for the Agilent
representative to unpack when the system is installed.
Uncrating an Agilent 3070 Series I System
Refer to Figure 9-1 on page 9-4 for uncrating a 307X
system and
Figure 9-2 on page 9-5 for uncrating a 317X
system.
WARNING
✸
Follow the unpacking instructions carefully and
do not work alone. A fully loaded 307X Series I
system with the shipping pallet might weigh 725
kilograms (1600 pounds). A fully loaded 307X
Series II or a 317X system with the shipping pallet
might weigh 455 kilograms (1000 pounds).
Table 9-1 System Shipping Pallets
System Type Pallets
317X Series I One pallet — Testhead only
307X Series I One pallet — Testhead and Support Bay on same pallet
317X Series II / 3 One pallet — Testhead only
307X Series II / 3 Two pallets — Testhead and Support Bay or Quick Verify on separate pallets
327X Series II / 3 One pallet — Testhead only
79000 One pallet — Testhead only
