© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-5
Chapter 10: Site Preparation – Power Requirements for Older Systems: Series 3 Power Requirements and Connections (Prior to May 2001)
Series 3 Power
Requirements and
Connections (Prior
to May 2001)
This section contains:
■ Sizing the Input Wires and Circuit Breakers, 10-5
■ Series 3 / 79000 Power Distribution, 10-9
■ 327X 1-Module System AC Outlets, 10-17
■ 79000 - 1-Module System AC System, 10-28
■ 317X 2-Module System AC Outlets, 10-39
■ 307X 4-Module 1-PDU System AC Outlets, 10-50
■ 307X 4-Module 2-PDU System AC Outlets, 10-60
■ E2195/E2197A xDSL/POTS Bay AC Outlets, 10-67
Sizing the Input Wires and Circuit Breakers
All 3070 and 3070PC systems should be installed with
a 30-amp breaker or fuse in each phase of the incoming
power. The modules and instruments in the testhead are
protected by circuit breakers or fuses in the power
distribution unit.
Table 10-1 on page 10-6 shows the Full Load Amp
(FLA) for each system type and for each 3-phase power
option.
Table 10-2 on page 10-7 shows FLA for each system
type and for each single-phase power options.
One of two different power cords and plugs are attached
to each 3-phase system, depending on the country where
the system will be installed:
■ E1135-61611 - uses #10 AWG 5-conductor cord
with NEMA plug that mates with NEMA L21-30.
Used by North America. Receptacle available
locally.
■ E1135-61610 - uses 5x6 mm
2
5-conductor cord
with a IEC 60309 plug and mating receptacle.
Used Internationally.
