© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 4-2
Chapter 4: Site Preparation – Structural Requirements: Floor Requirements
Floor Requirements This section contains:
â– Introduction, 4-2
â– Anti-Static Surface, 4-4
â– Immobilization for the EFS Board Handler, 4-5
Introduction
The Agilent 3070 / 79000 family system tester
(testhead and Support Bay, if included) is the heaviest
part of the system. The controller, test development
centers, and test development stations present no special
load-bearing concern. Table 4-1 shows the approximate
weights of fully-loaded systems.
Table 4-1 System weights
System Type Product Weight
3070 Series I Testhead 370 kg (750 lb)
Support Bay 205 kg (450 lb)
Testhead and Support Bay on Pallet 725 kg (1600 lb)
307X Series I Testhead 454 kg (1000 lb)
Testhead on pallet 526 kg (1160 lb)
Maximum Point Floor Loading (each leg) 275 kg (600 lb)
Support Bay 209 kg (460 lb)
Support Bay on pallet 277 kg (610 lb)
Maximum Point Floor Loading (each leg) 185 kg (400 lb)
