© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-114
Chapter 10: Site Preparation – Power Requirements for Older Systems: Tester Power Requirements (Series I/II)
E1099A PDU Electrical Requirements
Table 10-20 on page 10-114 shows the electrical
requirements and line configuration options for the
E1099A PDU. Maximum current describes option OE3
(200V) current requirements for a system with all
optional equipment; other power options and
configurations will require less current. In option 0EF
(208 Volts), all three phases are used in an unbalanced
configuration.
Table 10-21 on page 10-117 through
Table 10-27 on page 10-123 provide a means of more
accurately calculating the power requirements for
various system configurations with each power option.
CAUTION
The two- and three-phase options are unbalanced.
Therefore, the neutral conductor should be the
same size as the line conductors. (Refer to
Figure
10-70 on page 10-145.)
Table 10-20 E1099A PDU power options
Frequency: 47 to 63 Hz
Voltage:
Option 0E3 200 V (182–222 V rms) 1 phase neutral center tap
Option 0EF 208 V (189–230 V rms) 3 phase wye with neutral
Option 0EB 220-230 V (200–244 V rms) 1 phase no neutral
Option 0EG 110/220-115/230 V (200–244 V rms) 1 phase neutral center tap
Option 0EC 240 V (218–266 V rms)1 phase neutral center tap 1 phase no neutral
Option 0EH 120/240 V (218–266 V rms) 1 phase neutral center tap
Maximum Total Current:
1 module 41 A
2 modules 60 A
3 modules 77 A
4 modules 96 A
