Chapter 4: Site Preparation – Structural Requirements: Moving Access Requirements
Moving Access
Requirements
This section contains:
■ Introduction, 4-6
■ Dimensions of the Crated System, 4-6
■ Dimensions of the Uncrated System, 4-8
■ Ramp Requirements, 4-11
■ Hallway and Door Width Requirements, 4-11
Introduction
The Agilent 3070 / 79000 family board test system is
shipped from the factory on one large crate (on a pallet)
and several smaller crates or boxes. The 307X Series I
testhead includes the Support Bay on the same pallet.
The 307X Series II and Series 3 testhead does not
include the Support Bay on the same pallet; the Support
Bay is shipped on a separate pallet. The 317X and 317X
Series II and Series 3 systems do not include a Support
Bay. The large testhead crate may be too large to move
to your system’s destination. If you cannot move it to its
final destination, you will need to unpack the testhead
and roll it on its casters (see Chapter 9). Other smaller
boxes, containing the controller and test development
hardware, should not present access problems.
Dimensions of the Crated System
The dimensions of the 3070 / 79000 family crated
systems are shown in Table 4-2.
Table 4-2 Dimensions of the crated system
System Type Dimension Measurement
307X Series I Testhead
(with Support Bay)
Length 2440 mm (96 in)
Width 1080 mm (42.5 in)
Height 1600 mm (63 in)
317X Series I Testhead
(without Support Bay)
Length 1740 mm (68.25 in)
Width 1080 mm (42.5 in)
Height 1600 mm (63 in)
