Agilent Technologies 3070 Series User Manual

© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 4-7
Chapter 4: Site Preparation – Structural Requirements: Moving Access Requirements
3X7X Series II, Series 3
and 3070PC Testhead
(without Support Bay)
Length 2095 mm (82.5 in)
Width 1080 mm (42.5 in)
Height 1600 mm (63 in)
3X7X Series II, 3
Support Bay
Length 1120 mm (44 in)
Width 860 mm (31 in)
Height 1600 mm (63 in)
327X Series II Quick
Verify
Length 875 mm (25.6 in)
Width 625 mm (24 in)
Height 980 mm (38.6 in)
79000 Testhead Length 2095 mm (82.5 in)
Width 1080 mm (42.5 in)
Height 902 mm (33.5 in)
3X79 Series II POTS Bay Length 1120 mm (44 in)
Width 860 mm (34 in)
Height 1860 mm (73 in)
Table 4-2 Dimensions of the crated system (continued)
System Type Dimension Measurement
