Agilent Technologies 3070 Series - 307 X 4-Module 1-PDU System AC Outlets

© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 11-62
Chapter 11: Site Preparation – Series 3 / 79000 Current Reduction Conversion: Series 3 Current Reduction Conversion Procedure
307X 4-Module 1-PDU System AC Outlets
Figure 11-41 307X 4-module 1-PDU system
Outlet 0
Support Bay
(Rear View)
Testhead (Rear View)
Outlet 2
Outlet 3Outlet 1
