© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 6-8
Chapter 6: Site Preparation – Power Requirements: Power Requirements
Connecting Power to the PDU
Beginning with the serial numbers shown in Table 6-2,
all systems are shipped with SO
1
power cords and plugs
factory-wired to the PDU.
One of two different power cords and plugs are attached
to the PDU depending on the country where the system
will be installed:
International — E1135-61610: uses 5x6 mm
2
5-conductor cord with a IEC 60309 plug and
mating receptacle (see Figure 6-4 on page 6-9).
North America — E1135-61611: uses #10 AWG
5-conductor cord with NEMA plug that mates
with NEMA L21-30 (see Figure 6-5 on
page 6-10). The female receptacle is available
locally.
1 Service with Oil resistant jacket
Table 6-2 Beginning serial numbers of systems shipped
with power cords
System Type Testhead
Product
Testhead Serial
307X E9900A US38240533
317X E9998A US38240410
327X E9997A US38240248
79000 E2190A US38050137
