© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 6-12
Chapter 6: Site Preparation – Power Requirements: PDU Wiring Diagrams
PDU Wiring
Diagrams
Table 6-4 on page 6-13 directs you where to find wiring
diagrams in this chapter for 3070 Series 3 and 79000
testheads and E2197A xDSL / POTS bays.
If you have a Series I or Series II system, refer to
Chapter 10, Site Preparation – Power Requirements
for Older Systems.
NOTE
Beginning in November 2000, only 3-phase
power options are available for 3070, 79000 and
E2197A products.
NOTE
Beginning in May 2001, the PDU includes
20-centimeter-long (8-inch) power cords with
female plugs hard-wired to the output terminal
block. This means that the testhead outlet boxes
can be unplugged rather than un-wired from the
terminal block, making PDU replacement much
easier. The following figures do not show this
plug connection between the terminal block and
the outlet boxes.
