Chapter 10: Site Preparation – Power Requirements for Older Systems: Series 3 Power Requirements and Connections (Prior to May 2001)
327X 1-Module System AC Outlets
Figure 10-2 327X 1-module system
Outlet 2
Testhead (Rear View)
Outlet 3
Outlet 1
