© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 9-8
Chapter 9: Site Preparation – Receiving and Moving Instructions: Uncrating The System
Uncrating an Agilent 3070 Series II/3 and Agilent
79000 System
WARNING
✸
The testhead weighs approximately 454 kilograms
(1000 pounds). To avoid personal injury, follow
these instructions carefully and do not work alone.
The shipping straps are stretched taut and will
whip when cut. Wear eye protection when cutting
straps.
In uncrating the testhead, you will roll the testhead
down a ramp from one end of the pallet. To do this you
will need an area approximately 8 feet (2.5 meters) wide
by 18 feet (5.5 meters) long.
Tools Needed to Uncrate the Testhead
■ Utility knife
■ Cordless drill with hex power shank from
Agilent/MTBU
■ 9/16-inch and 3/4-inch sockets with ratchet and
6-inch (150-millimeter) extension
Uncrating Procedure
1 Cut the strap around the ramp. Lift the ramp off the
pallet and set it aside. Remove the plastic bag
covering the testhead and discard it. Discard all
packing materials.
2 Remove two 150-millimeter (6-inch) bolts from a
plastic bag attached to the ramp.
3 Figure 9-3: Remove the “Removable End” board
from the pallet:
a Remove bolts 1 through 4 from the sides and
bottom of the pallet.
b Remove bolts 5 and 6 from the platform.
To Next Page
