© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 4-8
Chapter 4: Site Preparation – Structural Requirements: Moving Access Requirements
Dimensions of the Uncrated System
When removed from the crate (pallet), the system
(testhead and Support Bay) can be rolled on its casters.
This configuration is easier to move.
CAUTION
✸
When moving a 307X testhead like this, you must
move the testhead and Support Bay together,
subject to the restraint imposed by the cabling
between them. Be very careful not to damage
system cables during moving!
Table 4-3 on page 4-8 describes the dimensions of the
uncrated testhead and Support Bay. Chapter 9 describes
moving the tester on its casters.
Table 4-3 Dimensions of the uncrated system
System Type Dimension Measurement
307X Series I Testhead
(with Support Bay)
Length 2100 mm (83 in)
Width 1000 mm (40 in)
Height 1250 mm (49 in)
317X Series I Testhead
(without Support Bay)
Length 1500 mm (59 in)
Width 870 mm (34 in)
Height 900 mm (35 in)
307X and 317X Series II
Testhead (without
Support Bay)
Length 1860 mm (73.5 in)
Width 820 mm (31 in)
Height 900 mm (35 in)
