© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 5-4
Chapter 5: Site Preparation – Environmental Requirements: Air Temperature Requirements
NOTE
The air temperature inside the system is not
considered stable until the system has been
powered for at least 30 minutes.
If the sensor finds that the air temperature inside the
system is too high, the system will shut down; typically,
the over-temperature shutdown point is 55 C (131 F).
See Cooling Requirements on page 5-4 for information
on air conditioning requirements. See Table 5-1 on
page 5-3 for more temperature and humidity
specifications.
Cooling Requirements
Design the site cooling capability using the heat
dissipation estimates in Table 5-2. The numbers are for
testheads with fully loaded modules, Serial Test power
supplies, and fully loaded support bays.
Table 5-2 System heat dissipation
Number of Modules Dissipation
3X7X Series I Testhead (with
Support Bay)
1 Module 5100 BTU (1.5 kW)
2 Modules 8500 BTU (2.5 kW)
3 Modules 11900 BTU (3.5 kW)
4 Modules 15300 BTU (4.5 kW)
3X7X Series II, Series 3, including
3070PC, Testhead (with Support
Bay)
1 Module 10500 BTU (3.1 kW)
2 Modules 19700 BTU (5.8 kW)
3 Modules 28500 BTU (8.4 kW)
4 Modules 3700 BTU (10.9 kW)
327X / 79000 1 Module 10500 BTU (2.5 kW)
3X79CT POTS Bay 8 Channels 8500 BTU (2.5 kW)
44900A EFS Board Handler 1000 BTU (0.3 kW)
