© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-4
Chapter 10: Site Preparation – Power Requirements for Older Systems: Introduction
Figure 10-1 Rear views of the 3070 / Series II family systems
317X Series II Testhead
E1135A or E1135B PDU
317X Series I Testhead
307X Series II Testhead with Support Bay
307X Series I Testhead with Support Bay
SYS_ID.WPG
E1170-80003 PDK
PDU #1 (Main):
E1135A or
E1135B
PDU #2 (Branch):
E1135A or
E1135B
E1135A or E1135B PDU (Main) E1135A or E1135B PDU (Branch)
View with rear
door open
Port3
Port2
In0ut
E1135B or E1135C PDU (Main)
327X Series II Testhead
