© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 7-10
Chapter 7: Site Preparation – Compressed Air and Vacuum Requirements: Vacuum Requirements
Figure 7-5 24-Vdc air-piloted solenoid vacuum example
Support Bay
Testhead
01
23
Air Line
Vacuum
Source
Pressure
Meter
24 Vdc
Air-Piloted
Solenoid
Filter
site_prep3.wpg
1-inch flexible
tubing
