Agilent Technologies 3070 Series User Manual

© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 8-8
Chapter 8: Site Preparation – Communications Cabling Requirements: Local Area Network Requirements
Figure 8-3 An example 3070 Series 3 / 79000 network
*15.3.112.2
Sys Card
*15.3.112.4
Mod. 0
ControlXT
*15.3.112.5
Mod. 1
ControlXT
*15.3.112.6
Mod. 2
ControlXT
*15.3.112.7
Mod. 3
ControlXT
HUB
10Base2
Converter
10BaseT
50 5 Terminator
1250-0207
50 5 Terminator
1250-2076
Test
Server
Test
Server
Router /
Gateway
as needed
Public LAN
/Backbone
Public LAN
/Backbone
System 1 on Hub
System 2..n on Hub
s3lan
0960-1009
10Base2
Testhead
Controller
BNC Tee
1250-0781
External Site Lan
To AC
Power
Control Cables
E4000-61628
10BaseT
*15.3.112.1 for HP-UX
* 15.x.xxx.x becomes 10.x.xxx.x beginning with systems shipped in May 2000
