© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-68
Chapter 10: Site Preparation – Power Requirements for Older Systems: Series 3 Power Requirements and Connections (Prior to May 2001)
Figure 10-52 E2195A xDLS / POTS Bay (shown with POTS options)
OTS1 WPG
Outlet 1 -
Line
Filter
PDU
Mains
Input
5678
To Gnd
1234
To Gnd
See Table
See Table
See Table
See Table
Customer Instruments
