© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 11-85
Chapter 11: Site Preparation – Series 3 / 79000 Current Reduction Conversion: Series 3 Current Reduction Conversion Procedure
Figure 11-62 Using a pigtail with the E1135C PDU
3070 System
Pigtail.wpg
PDU
AC Source Voltage
Added Power Receptacle on a short pigtail if the
E1135C PDU is used and the existing conductor
size of the power drop exceeds 10
2
mm (#8 AWG).
Power
Receptacle
Pigtail
Circuit
Breaker
or Fuses
To Next Page
