Agilent Technologies 3458A User Manual

274 Chapter 7 BASIC Language for the 3458A
depends on the individual sizes of the subprograms. A typical subprogram
containing 10 commands (including the SUB and SUBEND commands)
might average about 600 bytes. Refer to chapter 3 for more information on
memory usage.
Can I Nest Subprograms?
Yes! Nesting subprograms is the ability to have one subprogram call
(execute) another subprogram. You can nest up to 10 subprograms.
Writing and Loading Subprograms
The subprogram example programs in this section illustrate relatively simple
3458A operations which you can copy and use in more complex mainline
programs of your own design. This section also shows how to create and edit
subprograms.
Note PROGRAMMING HINT
You should execute the SCRATCH command and download the
subprograms from your system controller at the beginning of your test
system program. This helps memory management for the 3458A and
ensures that the subprograms are downloaded and ready when they are
needed.
Executing the SUB command instructs the 3458A to store all subsequent
commands, until the SUBEND command, in the specified subprogram.
Subprogram names may contain up to 10 characters. The first character must
be a letter (A–Z) but the remaining nine characters can be letters, numbers
(0–9), the underscore character ("_"), or the question mark ("?"). Subprogram
names must not be the same as 3458A commands or parameters, previously
defined array or variable names, or stored state names.
The following program shows how to create a simple subprogram which
configures the multimeter to make three dc voltage measurements.
10 OUTPUT 722; "SUB DMM_CONF"
20 OUTPUT 722; "DCV8,0.00125"
30 OUTPUT 722; "NRDGS 3"
40 OUTPUT 722; "TRIG SGL"
50 OUTPUT 722; "SUBEND"
60 END
The two statements SUB DMM_CONF and SUBEND along with the three
commands on line 20, 30, and 40 form the subprogram named DMM_CONF.
When a subprogram is entered, the 3458A checks for syntax errors just like
any other commands. If the syntax is not correct, an error is generated and
the command is not stored in the subprogram. You must then edit your
subprogram in the system controller and download it again. The 3458A stores
the subprogram in non-volatile memory. You can then execute the
subprogram from either the front-panel keyboard or the system controller.
