Chapter 3 Configuring for Measurements 53
30 END
In addition to the PRESET NORM command, the multimeter has a PRESET
FAST command (configures for fast readings and transfers), which is
discussed in Chapter 4, and a PRESET DIG command (configures for DCV
digitizing) which is discussed in Chapter 5.
Specifying a
Measurement
Function
The first parameter of the FUNC command selects the measurement function.
For example, to specify DC voltage measurements, send:
OUTPUT 722;"FUNC DCV"
The FUNC command header is optional and can be omitted. For example,
you can specify DC voltage measurements simply by sending:
OUTPUT 722;"DCV"
The remaining examples in this chapter use the shortened (no FUNC header)
version. Table 11 shows the various measurement function parameters and
the function selected by each.
* Refer to Chapter 5Digitizing for more information on these functions.
Autorange When the autorange function is enabled, the multimeter samples the input
prior to each reading (when readings are being triggered) and automatically
selects the correct range. Since autorange requires sampling the input,
measurements made with autorange enabled take longer than measurements
made on a fixed range. In the power-on/PRESET NORM state, autorange is
enabled. If you intend to measure a fairly stable input signal, you can use the
ARANGE ONCE command to allow autorange to select the correct range
(when readings are triggered) and then disable autorange for subsequent
readings. This allows you to get the automatic range selection advantage of
autorange and also the speed advantage of readings made with autorange
disabled. To do this, send:
Table 11: Measurement Function Parameters
Function Parameter Description
ACDCI Selects AC current measurements, DC coupled
ACDCV Selects AC voltage measurements, DC coupled
ACI Selects AC current measurements, AC coupled
ACV Selects AC voltage measurements, AC coupled
DCI Selects DC current measurements
DCV Selects DC voltage measurements
DSAC * Direct sampling, AC coupled
DSDC * Direct sampling, DC coupled
FREQ Selects frequency measurements
OHM Selects 2-wire ohms measurements
OHMF Selects 4-wire ohms measurements
PER Selects period measurements
SSAC * Sub-sampling, AC coupled
SSDC * Sub-sampling, DC coupled
