134
Programming Examples
Example 2 - Status Registers and Queues
890 Value=Value-Bit
900 !
910 ! If MAV is set, then get and display the output que
ue contents
920 !
930 IF Z=0 THEN
940 IF Bit=16 THEN
950 ENTER Att;A$
960 PRINT TABXY(21,18);A$
970 END IF
980 END IF
990 !
1000 ! If the bit is not set, then display 0
1010 !
1020 ELSE
1030 PRINT TABXY(Xpos,Ypos);"0"
1040 END IF
1050 !
1060 ! Set up for the next iteration
1070 !
1080 Bit=Bit DIV 2
1090 Xpos=Xpos+4
1100 UNTIL Bit=0
1110 !
1120 ! Now that the status byte is displayed, get the Standar
d Events
1130 ! Status Register
1140 !
1150 OUTPUT Att;"*ESR?"
1160 ENTER Att;Value
1170 !
1180 ! Set up to display the ESR
1190 !
1200 Ypos=12
1210 NEXT Z
1220 !
1230 ! Read and display any messages in the error queue
1240 !
1250 REPEAT
1260 OUTPUT Att;"SYSTEM:ERROR?"
1270 ENTER Att;Value,A$
The SYSTEM:ERROR? query gets the number of the last error in the error queue.
1280 IF Value<>0 THEN PRINT TABXY(21,17);Value,A$
1290 UNTIL Value=0
1300 !
1310 ! Clear the Status structure and reenable the interrupt be
fore returning
1320 !
1330 OUTPUT Att;"*CLS"
1340 ENABLE INTR 7
1350 !
1360 RETURN
1370 !
1380 END
