Making an Attenuation Sweep
The Manual Sweep
• STEP is the size of the attenuation factor change. This value is
always positive, even for a sweep of decreasing attenuation
factor. STEP cannot be set to a value greater than the difference
between START and STOP.
Starting the Setting Up
To select the manual sweep
1. Press S
WP.
2. If it is not already set, use the modify keys to set SWEEP to
MANUAL.
Editing the Parameters
To edit the value of the parameters
3. Press S
WP again to get START.
4. Edit the value of START with the Modify keys.
5. Press S
WP again to get STOP.
6. Edit the value of STOP with the Modify keys.
Figure 3-5 Editing the STOP Parameter
7. Press S
WP again to get STEP.
8. Edit the value of STEP with the Modify keys.
See “Using the Modify Keys” on page 29 for information on
editing with the Modify keys.
