31
Getting Started
The Manual Sweep
can edit the parameters for the sweep. START is the attenuation
factor at which the sweep begins, STOP is the attenuation factor
that ends the sweep, STEP is the size of the attenuation factor
change, and DWELL is the time taken for each attenuation factor.
Figure 1-3 The Parameters for an Automatic Sweep
If you have set up your sweep, then you press E
XEC to run it.
1.3 The Manual Sweep
A manual sweep is one where stepping from one attenuation factor
to the next is done by the user.
To select the manual sweep press SWP, and make sure that SWEEP
is set to MANUAL. By pressing S
WP repeatedly you can view and
edit the parameters for the sweep. START is the attenuation factor
at which the sweep begins, STOP is the attenuation factor that ends
the sweep, and STEP is the size of the attenuation factor change.
If you have set up your sweep, then you press E
XEC to run it. To go
to the next attenuation factor in the sweep, press
⇑ or ⇒. To go to
the previous attenuation factor in the sweep, press
⇓ or ⇐.
