30
Getting Started
Making an Attenuation Sweep
Figure 1-2 The Modify Keys
Editing a Number
Use
⇐ and ⇒ to move the cursor from digit to digit when editing a
number. Use
⇑ and ⇓ to change the value of a digit when editing a
number.
Editing a Non-Numeric Parameter
Use
⇑ or ⇒ to increment the parameter.
Use
⇓ or ⇐ to decrement the parameter.
1.2 Making an Attenuation Sweep
There are two types of attenuation sweep, automatic and manual.
Making an Automatic Sweep
An automatic sweep is one where stepping from one attenuation
factor to the next is done by the instrument.
To select the automatic sweep press SWP, and make sure that
SWEEP is set to AUTO. By pressing S
WP repeatedly you view and
