108
Remote Commands
INPut Commands
Description This command sets the calibration factor for
the instrument. This factor does not affect the
filter attenuation. It is used to offset the values
for the attenuation factor. The calibration factor
is used, with the attenuation factor (see
“:INPut:ATTenuation” on page 106) to set the
attenuation of the filter.
Attenuation
filter
(dB) = Att(dB) - Cal(dB)
You set the calibration by sending a value
(default units are dB), or by sending MIN, DEF
or MAX, which specify the minimum, default
and maximum values for the calibration factor.
The minimum value for the calibration factor is
-99.999dB. The default value is 0dB. The
maximum value is 99.999dB.
:INPut:OFFSet?
Syntax :INPut:OFFSet? [<wsp> MIN|DEF|MAX]
Description The query returns the current calibration factor,
in dB.
By sending MIN, DEF, or MAX with the query
the minimum, default or maximum value
possible for the calibration factor is returned.
Example OUTPUT 728;":INP:OFFS 32.15"
OUTPUT 728;":INP:OFFS?"
ENTER 728;A$
:INPut:OFFSet:DISPlay
Syntax :INPut:OFFSet:DISPlay
