167
Specifications
Specifications
C.2 Specifications
Specifications describe the instrument’s warranted performance.
Supplementary performance characteristics describe the
instrument’s non-warranted typical performance.
Specifications are measured at 1310nm and 1550nm using a laser
source, single-mode fiber and Agilent 81000AI or Agilent 81000SI
connector interfaces.
Table C-1 Specifications - Options 100, 101 and 201
•
[1]
Typical, depends on performance of external connector
Option 100 Option 101 Option 201
Standard High
Performance
High Return
Loss
Wavelength Range 1200 - 1650nm
Attenuation Range 60dB (excluding insertion loss)
Fiber Type 9/125
µm single-mode
Connector Type straight contact angled contact
Return Loss
[1]
>35dB >45dB >60dB
Insertion Loss (typ)
[2]
4.5dB 2.5dB
Attenuation Accuracy (linearity)
[3]
typical
<
±0.2dB
[4]
<
±0.1dB
[4]
<
±0.1dB
<
±0.05dB
Repeatability
typical
<
±0.01dB
<
±0.005dB
Polarization Dependent Loss
typical
<0.15dBpp
<0.075dBpp
<0.08dBpp
<0.02dBpp
Polarization Mode Dispersion 4fs
Useful Back-Reflection Range 9.0 to 35dB 5.0 to 45dB 5.0 to 60dB
