Agilent Technologies Infinity Binary Pump VL 1290

126 Agilent 1290 Infinity Binary Pump User Manual
9 Maintenance
Replacing the Solvent Selection Valve (SSV)
3
Remove the connector by pushing up the small clip at the
bottom of the connector.
4 Install a new SSV by inserting the connector and clipping
the SSV panel to the module top panel. Then re-install all
tubing connections, open shut-off valve and purge valve.
6
7
7
6
7'
7&
6'
6&
