Agilent Technologies Infinity Binary Pump VL 1290 User Manual

20 Agilent 1290 Infinity Binary Pump User Manual
2 Site Requirements and Specifications
Specifications
Specifications
Tab le 2 Performance specifications
Type Specification Comments
Hydraulic system Two dual pistons in series pumps
with proprietary servo-controlled
variable stroke design and smooth
motion control.
Settable flow range Setpoints 0.001 —2 ml/min, in
0.001 ml/min increments.
Executed in 300 pl/step
increments
Flow precision ≤0.07 % RSD or 0.005 min SD,
whatever is greater
(0.2 —2.0 ml/min).
Based on retention time at
constant room temperature.
Flow accuracy ±1 % or 10 µl/min, whatever is
greater.
Pumping degassed H
2
O at
10 MPa (100 bar)
Pressure operating
range
Operating pressure range 120 MPa
(1200 bar), up to 2 ml/min.
Pressure pulsation <1 % amplitude or < 0.5 MPa (5 bar),
whatever is greater.
At 1 ml/min water
Compressibility
compensation
Automatic, pre-defined, based on
mobile phase selection.
Gradient formation High pressure binary mixing.
Delay volume Jet Weaver V35: <45 µl
Jet Weaver V100: <75 µl
JetWeaver generally
recommended. For applications
requiring lowest delay volumes,
JetWeaver can be removed out of
the flow path. Delay volume is
then solely determined by the
volume of the connection
capillary.
Composition range Settable range: 0 – 100 % Recommended range: 1 — 99 %
or 5 µl/min per channel,
whatever is greater.
