Agilent Technologies Infinity Binary Pump VL 1290

Agilent 1290 Infinity Binary Pump User Manual 35
Installing the Module
3
Flow connections to the pump
Flow connections to the pump
The pump is shipped with tubing and capillary connections installed between
solvent selection valve, degassing unit, pump heads, pressure sensor, purge
valve and Jet Weaver. This section describes the installation of additional flow
connections.
?ZiLZVkZg
9Z\VhhZg
HdakZcihZaZXi^dckVakZ
Ejbe]ZVYh
Ejg\ZkVakZ
EgZhhjgZhZchdg
